Metadata Querying for Object Storage feat. Elixir

Introduction

I admit it. My first Tigris blog post about Eager and Lazy caching was kind of basic. It was important to cover the ground-work. The CDN aspect is important and I do like the summon-your-data pre-fetch header a lot. Now we get to the significantly more disruptive stuff. The things that while Tigris is an S3-compatible API it also provides features that enable entirely new use-cases and push the boundaries of what you can do with object storage. Let's see if we can't set your internal constraint-solver aflame with possibilities.

First a bit of setup. Again, this post is also a Livebook which means that you can run all of it either locally with Livebook Desktop or on Fly.

Mix.install(
  [
    {:ex_aws, "~> 2.5"},
    {:ex_aws_s3, "~> 2.5"},
    {:hackney, "~> 1.20"},
    {:poison, "~> 3.0"},
    {:sweet_xml, "~> 0.6"},
    :jason,
    :req
  ],
  config: [
    ex_aws: [
      access_key_id: [{:system, "LB_AWS_ACCESS_KEY_ID"}],
      secret_access_key: [{:system, "LB_AWS_SECRET_ACCESS_KEY"}],
      endpoint_url_s3: [{:system, "LB_AWS_ENDPOINT_URL_S3"}],
      region: [{:system, "LB_AWS_REGION"}],
      s3: [scheme: "https://", host: "fly.storage.tigris.dev", port: 443]
    ]
  ]
)

alias ExAws.S3

bucket = System.fetch_env!("LB_BUCKET_NAME")

# Get some files, upload some files
# If you run this many times github might get cranky

%{
  "manifesto.txt" =>
    "https://ia800408.us.archive.org/26/items/HackersManifesto/Hackers-manafesto.txt",
  "sample.jpg" => "https://underjord.io/assets/images/lawik-square.jpg",
  "lawik.json" => "https://api.github.com/users/lawik",
  "underjord.svg" => "https://underjord.io/img/logo2.svg",
  "globe.webp" =>
    "https://cdn.prod.website-files.com/657988158c7fb30f4d9ef37b/6582a4f8d777a7f9c79bee68_Globally%20Distributed%20S3-compatible.webp"
}
|> Enum.map(fn {name, url} ->
  %{body: body, headers: headers} = Req.get!(url, decode_body: false)
  type = headers["content-type"] |> hd() |> String.split(";") |> hd()
  # Spacing in time for demo purposes
  :timer.sleep(1000)
  S3.put_object(bucket, name, body, content_type: type) |> ExAws.request!()
end)

What is Metadata Querying?

If you read back on the blog the engineering team at Tigris are very excited about Foundation DB and that is the underpinning for the entire metadata system and particularly for this feature. A fast and scalable metadata system lets Tigris find and fetch data with much lower latency than is typical of object storage. A highly capable metadata system allows Tigris to do more with metadata.

Let's talk metadata querying. It allows us to perform SQL-style queries on our object metadata and importantly sort it based on metadata. Currently three fields are supported:

• Content-Type meaning the mimetype, so "image/jpeg", "text/html" or "application/json".
• Content-Length which holds the number of bytes the object takes up on disk.
• Last-Modified a timestamp for when the object last changed.

It is all done via a custom header to fit within the bounds of the S3 API. You can do a lot with this. Some of it is straight up practical.

Fetching a range of mime types

Fetching a set of content types. Not just specific ones but even based on a prefix. The comparisons specified here are a little bit unusual as they are range queries. Anything between "image/" and "image0" indicates essentially everything that starts with "image/".

This is incredibly awkward to do in many object storage providers.

bucket
|> S3.list_objects_v2(
  headers: %{
    "X-Tigris-Query" => ~s(`Content-Type` > "image/" and `Content-Type` < "image0")
  }
)
|> ExAws.request!()
|> Map.fetch!(:body)
|> Map.fetch!(:contents)

Others are very flexible and quite the "we can't wait to see what you do with it" such as:

Ordering/sorting

You can query three values at this point. Content-Type, Content-Length (file size) and Last-Modified. All of these are practical but combined with the ORDER BY feature which lets you sort the result of a query on on of these fields you suddenly get something wildly powerful. You get ordering.

bucket
|> S3.list_objects_v2(
  headers: %{
    "X-Tigris-Query" => ~s(`Content-Length` >= 0 ORDER BY `Last-Modified` DESC)
  }
)
|> ExAws.request!()
|> Map.fetch!(:body)
|> Map.fetch!(:contents)

Ordering gives us the fundamentals for a lot of interesting stuff. It is a building block for many types of data stores and most object storage don't make this an easy question to answer without the risk of paging through thousands of items to find the most recent one.

You can build a Write-Ahead Log. You can do Event Sourcing. These require consistent ordering and a source that will serialize incoming data for you and determine the order. Tigris will.

Write at local speed, anywhere, globally. Read out locally as if talking to a CDN. But use it for complex and interesting functionality. Use it as the source of truth, the coordinating layer, a super simple cloud sync for your local-first application. Along with presigned URLs or even signed prefix uploads that you can have some very interesting stuff where you very rarely talk to your application server. Very .. dare I say serverless? Oh, right, no, that was taken.

Check the docs to see what operators you have available to you. I'm sure you can come up with more neat tricks to pull with this.

I see the content types, file sizes and timestamp all matter in various ways depending on what type product you are building. What could it enable for yours?

Fundamentally this functionality can remove the need for a separate metadata store to track typical things, like the order of files or mimetypes for later filtering. And if you've tried to lean on object storage for file storage without also writing a metadata record in some traditional database you've regretted it the moment you want to provide some sortable headers for a file list. Or want to show the 3 most recent uploads among thousands.

Because of how I'm wired it makes me want to try absolutely filthy cheap ideas about how to implement a microblog with a chronological timeline. Your servers only job would be providing presigned URLs or even sign for public uploads for a whole prefix for creating new entries and presigned cookies for fetching entries if the bucket isn't public. By making a very particular design you can really make something quite remarakble in terms of pricing and efficiencies.

It reminds me of the first time I heard of the potential latency advantages of satellite Internet. Shoot up. Shoot straight across. Shoot down. In this case. Upload to the closest bit of cloud, spread all across, download where needed. You don't need the roundtrips. You can answer simple queries by only speaking S3 API with some Tigris special sauce. CDN-speed reads, CDN-speed writes and no in-between application server.
