Skipping the boring parts of building a storage platform using FoundationDB

· 9 min read
Himank Chaudhary
Ovais Tariq

Building a new storage platform

The most complicated and time-consuming parts of building a new storage system are usually the edge cases and low-level details. Concurrency control, consistency, handling faults, load balancing, that kind of thing. Almost every mature storage system will have to grapple with all of these problems at one point or another. For example, at a high level, load balancing hot partitions across brokers in Kafka is not that different from load balancing hot shards in MongoDB, but each system ends up re-implementing a custom load-balancing solution instead of focusing on their differentiating value to end-developers.

This is one of the most confusing aspects of the modern data infrastructure industry, why does every new system have to completely rebuild (not even reinvent!) the wheel? Most of them decide to reimplement common processes and components without substantially increasing the value gained from reimplementing them. For instance, many database builders start from scratch when building their own storage and query systems, but often merely emulate existing solutions. These items usually take a massive undertaking just to get basic features working, let alone correct.

Take the OLTP database industry as an example. Ensuring that transactions always execute with "linearizable" or "serializable" isolation is just one of the dozens of incredibly challenging problems that must be solved before even the most basic correctness guarantees can be provided. Other challenges that will have to be solved: fault handling, load shedding, QoS, durability, and load balancing. The list goes on and on, and every new system has to at least make a reasonable attempt at all of them! Some vendors rode the hype wave of NoSQL to avoid providing meaningful guarantees, such as not providing linearizability in a lot of cases, but we think those days are long gone.

Vendors are spending so much time rebuilding existing solutions, they end up not solving the actual end users' problems, although ostensibly that's why they decided to create a new data platform in the first place! Instead of re-inventing the wheel, we think database vendors should be focused on solving the user's actual pain points.

The good news is there is a growing trend in the industry to reuse great open source software as a building block for higher level data infrastructure. For example, some vendors realized that a local key-value store like RocksDB could be used to deliver many features and enforce an abstraction boundary between the higher level database system and storage. They still hide RocksDB behind a custom API, but get to leverage all the development and testing effort it has received over the years. This can result in new systems that are both robust (durable, correct) and performant at the single-node level in a very short amount of time.

That said, even if all these storage systems magically used RocksDB under the hood, the problem of a complicated data infrastructure with many different components and data pipelines wouldn't be solved. That's because, even if all your storage systems use RocksDB under the hood, there is no common domain to perform transactions across them. After all, RocksDB is only a local key-value store.

While a local key-value store is a great abstraction for separating the storage engine from the higher-level system, Google took this a step further with Spanner, which is a SQL database built on a distributed key-value store. CockroachDB is another example of a SQL database built on top of a distributed key-value store. The distributed key-value store interface shifts the hard problems of consistency, fault tolerance, and scalability down into the storage layer and allows database developers to focus on building value-added features database users actually need.

Why Tigris leverages FoundationDB for its Metadata Storage layer


Until a few years ago, the open-source community did not have any viable options for a stand-alone, production-ready distributed key-value store with interactive transactions. FoundationDB, used by Apple, Snowflake, and others is such a system. It provides the same consistency and isolation guarantees as Spanner - strict serializability, and has an amazing correctness story through simulation testing. FoundationDB exposes a key-value API, similar to RocksDB, but it automatically scales horizontally to support petabytes of data and millions of operations per second in a single deployment on a modest amount of commodity hardware.

Tigris uses FoundationDB's transactional key-value interface for its underlying metadata storage. This separation of compute from storage allows Tigris to focus its attention on higher level concerns, instead of lower level ones. In other words, we leverage FoundationDB to handle the hard problems of durability, replication, sharding, transaction isolation, and load balancing so we can focus on higher level concerns.

Building a new storage platform on top of an existing distributed transactional key value interface like FoundationDB heavily skews the implementation towards "correct and reliable by default", even in the face of extreme edge cases. Many existing distributed databases still struggle to pass the most basic aspects of Jepsen testing even after over a decade of development. At Tigris, we greatly value correctness, reliability, and user experience. The generic abstraction of a transactional, sorted key-value store is flexible enough to support many kinds of access patterns, as well as enable rapid feature development. For example, a secondary index is just another key-value pair pointing from the secondary index key to the primary index key. Searching for records via this secondary index is as simple as a range scan on the key-value store and doing point reads on the primary index to retrieve the records. Ensuring the secondary index is always consistent only requires that the secondary index key is written in the same FoundationDB transaction in which the primary record is updated.

We use FoundationDB's transactions to ensure the invariants of these data structures remain intact regardless of the different failure modes the cluster might encounter.

  • Tigris encodes index keys using the FoundationDB's key encoder. It accepts high level data structures like arrays, strings, and numbers and encodes them into a lexicographically sortable byte string. Encoded keys are a common language for different components inside Tigris to communicate with.
  • Tigris Streams are powered by FoundationDB's support for "baking" a transaction's commit timestamp into a key, which allows reading all mutations in the total order of transactions committed into the database.

So why do we feel comfortable trusting FoundationDB with our most critical data? In a nutshell, it is because while perhaps lesser known, FoundationDB is one of the most well tested and battle hardened databases in the world.

FoundationDB's correctness and fault tolerance

Data Integrity

FoundationDB has more comprehensive testing than almost any other database system on the market. It relies on simulation testing, an approach where an entire FoundationDB cluster can be deterministically simulated in a single operating system process, alongside a wide variety of test workloads which exercise the database and assert on various properties. Simulation testing allows the test runtime to speed up time much faster than wall clock time by skipping over all the boring moments where code is waiting for a timeout to happen, or a server to come back up after being rebooted. This means many more "test hours" can pass for each real hour dedicated to running tests, and these tests can be run in parallel across many servers to explore the state of possible failure modes even further.

There are very few databases which even come close to this level of testing. Those that do typically only simulate a small portion of their system, leaving many components untested by simulation and only relying on unit tests. FoundationDB even simulates the backup-restore process to ensure the operational tools are just as good as the database itself. After all, those kinds of tools are often just as important! No database is perfect, but simulation catches problems before they make it into a user facing release.

FoundationDB also receives extensive real-world testing at Apple and Snowflake. The releases are beta tested by them long before being released to the community to ensure simulation results match reality of running in chaotic cloud environments. It also provides Tigris with extremely powerful workload management features. FoundationDB is constantly evaluating the load of the cluster to determine when it is "too busy", and when that happens it will artificially slow down starting new transactions until the load is stable again. By forcing all the latency to the beginning of your transaction, FoundationDB ensures every operation after that experiences a consistent, low latency. Many other database systems lack any workload management features at all, which manifests as overloaded clusters requiring operators to shut down all the clients to get it back under control.

We previously mentioned that backup-restore functionality is tested in simulation. That's true of other features like disaster recovery, logging, and metrics too. These built-in tools are a core part of FoundationDB's developer experience. Many other database systems force you to use a third-party backup tool once you cross a small scale due to table locking or other concurrency problems. FoundationDB's backups and disaster recovery system are both streaming (so your recovery point objective can be measured in seconds instead of hours) and they work for large, busy databases, not just the toy sized ones.

Tigris operations and reliability

Reliable Data Flow

Tigris is built following a microservice architecture approach. This allows us to have separate components that can each be scaled independently. For example, separating storage from compute ensures a better distribution of resources. Some workloads will store a small amount of data that requires tons of CPU for processing queries, while others will store large amounts of data and use a tiny amount of CPU. We can right-size storage and compute resources separately so that valuable CPU and memory resources are never again stranded on a big instance which mostly sits idle because of high storage utilization.

Tigris expands on FoundationDB's integrated workload management features to provide more fine-grained workload management down to the individual bucket level.

All in all, FoundationDB provides Tigris a strong foundation for building a high quality storage platform.
